Rof Electro-optic modulator EDFA Optical Amplifier Ytterbium-Doped Fiber Amplifier YDFA Amplifier

Takaitaccen Bayani:

Amplifier na gani na'ura ce wacce ke karɓar wasu hasken siginar shigarwa kuma tana haifar da siginar fitarwa tare da mafi girman ƙarfin gani.Yawanci, abubuwan da aka shigar da abubuwan da ake fitarwa sune filayen Laser (da wuya wasu nau'ikan fitilun haske), ko dai suna yaɗuwa azaman katako na Gaussian a cikin sarari kyauta ko a cikin fiber.Ƙarawa yana faruwa ne a cikin abin da ake kira matsakaicin riba, wanda dole ne a "fitsa" (watau, samar da makamashi) daga waje.Yawancin amplifiers na gani ko dai na gani ne ko kuma na lantarki.
Daban-daban nau'ikan amplifiers sun bambanta sosai misali dangane da kaddarorin jikewa.Misali, kafofin watsa labaru masu ƙarancin ƙarfi-ƙasa-doped ribar Laser na iya adana ɗimbin makamashi, yayin da na'urori masu aunawa na gani suna ba da haɓakawa kawai muddun famfon yana nan.Kamar yadda wani misali, semiconductor Optical amplifiers suna adana ƙasa da makamashi fiye da na'urorin fiber, kuma wannan yana da mahimmancin tasiri ga sadarwar fiber na gani.


Cikakken Bayani

Rofea Optoelectronics yana ba da Kayan gani da kayan aikin photonics Electro-optic modulators

Tags samfurin

Siffar

* Karancin surutu
* ACC, AGC, APC Option
* SM da PM fiber Option
* Kashe kariyar famfo ta atomatik
* Ikon nesa
* Desktop, kunshin module zaɓi ne

20dbm EDFA Module

Aikace-aikace

• Amplifier na iya haɓaka ƙarfin (matsakaici) na fitarwar laser zuwa manyan matakan (→ master oscillator power amplifier = MOPA).
• Yana iya samar da mafi girman iko kololuwa, musamman a cikin huhu, idan an fitar da makamashin da aka adana a cikin ɗan gajeren lokaci.
• Yana iya haɓaka sigina masu rauni kafin gano hoto, don haka rage amo, sai dai idan ƙarar ƙarar ƙarar ta girma.
• A cikin dogon hanyoyin haɗin fiber-optic don sadarwar fiber na gani, dole ne a ɗaga matakin ƙarfin gani a tsakanin dogayen sassan fiber kafin bayanin ya ɓace a cikin amo.

Ma'auni

Siga

Naúrar

Mafi ƙarancin

Tna al'ada

Maximum

Tsawon zangon aiki

nm

1050

1100

Kewayon wutar siginar shigarwa

dBm

-3

0

10

Cikakken ikon gani na gani *

dBm

30

33

Fihirisar amo @ Input 0 dBm

dB

5.0

6.0

Shigar da keɓewar gani

dB

30

Fitarwa na gani keɓewa

dB

30

Dawo da asara

dB

40

Riba mai dogaro da polarization

dB

0.3

0.5

Shigar da zubewar famfo

dBm

-30

Fitar famfo yabo

dBm

-40

Wutar lantarki mai aiki tebur

V (AC)

80

240

Nau'in Fiber

HI1060

Fitar dubawa

FC/APC

Sadarwar sadarwa

Saukewa: RS232

Girman kunshin module

mm

90×70×18

tebur

320×220×90

Bayanin oda

ROF YDFA XX XX X XX
  Ytterbium-Doped Fiber Amplifier HP--High fitarwa nau'in Ƙarfin fitarwa:

20---20dBm

23---23dBm

30---30dBm

33---33dBm

Girman kunshin

D---tebur

M---module

Mai haɗa fiber na gani:

FA---FC/APC




  • Na baya:
  • Na gaba:

  • Rofea Optoelectronics yana ba da layin samfurin kasuwanci na masu daidaitawa na Electro-optic, Modulators na lokaci, Intensity Modulator, Photodetectors, Laser haske kafofin, DFB Laser, Optical amplifiers, EDFA, SLD Laser, QPSK modulation, Pulse Laser, Haske mai gano haske, Daidaitaccen hoto, direban Laser , Fiber na gani amplifier, Na gani ikon mita, Broadband Laser, Tunable Laser, Optical ganowa, Laser diode direba, Fiber amplifier.Har ila yau, muna ba da wasu na'urori na musamman don keɓancewa, kamar 1 * 4 tsararrun lokaci masu daidaitawa, ultra-low Vpi, da ultra-high extinction rabo modulators, da farko ana amfani da su a jami'o'i da cibiyoyi.
    Da fatan samfuranmu za su taimaka muku da bincikenku.
